Panel
|
23.8" (Fast IPS)
|
Pixel Pitch (mm)
|
0.2745 (H) × 0.2745 (V)
|
Effective Viewing Area (mm)
|
527.04 (H) × 296.46 (V)
|
Brightness (typical)
|
300 cd/m²
|
Contrast Ratio
|
1000 : 1 (Typical) 80 Million : 1 (DCR)
|
Response Time
|
0.3ms (MPRT) / 1ms (GtG)
|
Viewing Angle
|
178° (H) / 178° (V) (CR > 10)
|
Color Gamut
|
sRGB 127% (CIE1931) / DCI-P3 94% (CIE1976)
|
Color Accuracy
|
Delta E < 2
|
Optimum Resolution
|
1920 × 1080 @ 200Hz – DisplayPort, HDMI; 1920 × 1080 @ 240Hz (OC) – DisplayPort, HDMI
|
Display Colors
|
16.7 Million
|
Signal Input
|
HDMI 2.0 × 1, DisplayPort 1.4 × 1
|
HDCP Version
|
HDMI: 2.2, DisplayPort: 2.2
|
USB Hub
|
no
|
Power Supply
|
External 12VDC, 2.5A
|
Power Consumption (typical)
|
30W
|
Speakers
|
no
|
Line in & Earphone
|
Earphone
|
Wall-Mount
|
100mm × 100mm
|
Adjustable Stand
|
Tilt: -5° ~ 20°
|
Product without Stand (mm)
|
320.8 (H) × 539.7 (W) × 51.1 (D)
|
Product with Stand (mm)
|
433.3 (H) × 539.7 (W) × 196.2 (D)
|
Packaging (mm)
|
396 (H) × 603 (W) × 130 (D)
|
Product without Stand (kg)
|
2.93
|
Product with Stand (kg)
|
3.30
|
Product with Packaging (kg)
|
4.27
|
Cabinet Color
|
Black & Red
|
Regulatory Approvals
|
BSMI / CE / RoHS
|
What's in the box
|
DP Cable 1.5m × 1
|
