Information

Specification	Value
Model Name	XT8 (B-2-PK)
Network Standard	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, WiFi 4 (802.11n), WiFi 5 (802.11ac), WiFi 6 (802.11ax), IPv4, IPv6
Product Segment	AX6600 ultimate AX performance: 574 + 1201 + 4804Mbps
AX technology	Yes
Data Rate	- 802.11a: up to 54 Mbps - 802.11b: up to 11 Mbps - 802.11g: up to 54 Mbps - WiFi 4 (802.11n): up to 300 Mbps - WiFi 5 (802.11ac) (1024QAM): up to 4333 Mbps - WiFi 6 (802.11ax) (2.4GHz): up to 574 Mbps - WiFi 6 (802.11ax) (5GHz-1): up to 1201 Mbps - WiFi 6 (802.11ax) (5GHz-2): up to 4804 Mbps
Antenna	Internal antenna x 6
Transmit/Receive	- 2.4GHz 2x2 - 5GHz-1 2x2 - 5GHz-2 4x4
Memory	256 MB Flash, 512 MB RAM
Boosts speed	- OFDMA (Orthogonal Frequency Division Multiple Access) - Beamforming: standard-based and universal - 1024-QAM high data rate - 20/40/80/160 MHz bandwidth * The 160MHz bandwidth may be unavailable in the 5GHz band in some regions/countries due to regulatory restrictions.
Operating Frequency	2.4 GHz, 5 GHz-1, 5 GHz-2
Ports	- RJ45 for 2.5G BaseT for WAN x 1 - RJ45 for Gigabits BaseT for LAN x 3 - USB 3.1 Gen 1 x 1
Button	WPS Button, Reset Button, Power Switch
LED Indicator	Power x 1
Power Supply	- AC Input: 110V ~ 240V(50 ~ 60Hz) - DC Output: 19 V with max. 1.75 A current - DC Output: 12 V with max. 3 A current
Package content	ZenWiFi AX, RJ-45 Cable, Power Adapter, Quick Start Guide, Warranty Card
Product Weight (g)	716 g
AiMesh	AiMesh, Primary AiMesh router, AiMesh node
Router APP	ASUS Router APP
Alexa	Support Alexa skill
AiProtection	- AiProtection Pro - Malicious site blocking - Two-Way IPS - Infected Device Prevention and Blocking
Parental Control	Parental Control
Traffic Control	- Adaptive QoS - Traffic Monitor - Traffic Analyzer
Wireless	- IPv6 Wi-Fi Encryption: WPA2-PSK, WPA-PSK, WPA-Enterprise, WPA2-Enterprise, WPS support - UTF-8 SSID - Guest Network - Maximum Guest Network rule: Max 9 rules - WPS - WiFi MAC address filter - Maximum MAC filters: Max 64 rules - Wireless scheduler - Airtime fairness - RADIUS Client - Universal beamforming - Explicit beamforming
WAN	- Dual WAN - 3G/4G LTE dongle - DMZ - DDNS - Let's Encrypt - Safe browsing - DNS-over-TLS
LAN	- IGMP snooping - IPTV
VPN	- VPN Client L2TP - VPN Client OVPN - VPN Client PPTP - VPN Client WireGuard - VPN Server IPSec - VPN Server OVPN - VPN Server PPTP - VPN Fusion - VPN Server WireGuard
USB application	- File System: FS_Tuxera_HFS+, FS_Tuxera_NTFS, FS_Tuxera_vFAT, FS_ext2, FS_ext3, FS_ext4 - AiCloud - Download master - AiDisk - Media Server - Time Machine - Samba Server
Administration	- Operating mode: Wireless router mode, Range extender mode, Access point mode - Firewall - Maximum Firewall keyword filter: Max 64 rules - Maximum Firewall network service filter: Max 32 rules - Maximum Firewall URL filter: Max 64 rules - Wake on LAN (WOL) - Diagnosis tools - Feedback system - System log - New Device Connect Notification - Login Captcha - Connection Diagnosis - Security Scan - Auto Firmware Update
